• Tires, Front Two 11R22.5G Goodyear G661 HSA (496 rev/mile)
• Tires, Rear Four 11R22.5G Goodyear G661 HSA (496 rev/mile)
• Black Front Bumper w/2 Tow Hooks
• Black Side Windows Trim and Black Front Windshield Trim
• Black Door Handles
• Fixed Rear Window
• Light Tinted Glass
• Variable Intermittent Wipers
• Composite/Galvanized Steel Panels
• Front Splash Guards
• Side Steps
• Black Grille
• Hood Grille Mount
• Reverse Opening Rear Doors
• Aero-Composite Halogen Headlamps
• Cab Clearance Lights

• Radio AM/FM Stereo w/Aux Audio Input Jack & Clock -inc: With two speakers
• Radio w/Clock
• Fixed Antenna

• 30/0/30 Fixed Driver & Fixed Passenger w/Consolette - Vinyl
• Vinyl Front Seats w/Carpet Back Material
• Fixed Driver Seat
• Fixed Passenger Seat
• Manual Tilt Steering Column
• Fixed Rear Windows
• Front Cupholder
• Cruise Control w/Steering Wheel Controls
• Manual Air Conditioning
• Glove Box
• Full Cloth Headliner
• Urethane Gear Shift Knob
• Passenger Visor Vanity Mirror
• Partial Floor Console and 2 12V DC Power Outlets
• Delay Off Interior Lighting
• Full Vinyl/Rubber Floor Covering
• Instrument Panel Bin, Dashboard Storage, Driver And Passenger Door Bins
• Manual 1st Row Windows
• Trip Computer
• Analog Display
• 2 12V DC Power Outlets

• Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters

6.7L POWER STROKE V8 TURBO DIESEL - 270 HP, 675 LB-FT TORQUE @ 1600 RPM

• CARB clean idle label - may be removed if un-necessary (STD)

• Turbocharged
• Rear Wheel Drive
• Power Steering
• ABS
• Tires - Front All-Season
• Tires - Rear All-Season
• Tow Hooks
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• AM/FM Stereo
• Auxiliary Audio Input
• Vinyl Seats
• Adjustable Steering Wheel
• Trip Computer
• Cruise Control
• A/C
• Passenger Vanity Mirror
• Trip Computer

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 1500
• Cold Cranking Amps @ 0° F (2nd): 1500
• Cold Cranking Amps @ 0° F (3rd): 1500
• Maximum Alternator Capacity (amps): 200
• Weight Information
• Curb Weight - Front (lbs): 6712
• Curb Weight - Rear (lbs): 3989
• Gross Combined Wt Rating (lbs): 50000
• Suspension
• Suspension Type - Front: Leaf
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 10000
• Spring Capacity - Rear (lbs): 21000
• Axle Type - Front: Non-Independent
• Axle Type - Rear: Rigid Axle
• Axle Capacity - Front (lbs): 10000
• Axle Capacity - Rear (lbs): 21000
• Brakes
• Brake ABS System: 4-Wheel
• Brake ABS System (Second Line): 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 15
• Rear Brake Rotor Diam x Thickness (in): 15
• Front Drum Diam x Width (in): 15
• Tires
• Front Tire Order Code: TCT
• Rear Tire Order Code: RCT
• Front Tire Size: 11.0R22.5 AS
• Rear Tire Size: 11.0R22.5 AS
• Front Tire Capacity (lbs): 12350
• Rear Tire Capacity (lbs): 23360
• Revolutions/Mile @ 45 mph - Front: 496
• Revolutions/Mile @ 45 mph - Rear: 496
• Wheels
• Front Wheel Size (in): 22.5 X 7.5
• Rear Wheel Size (in): 22.5 X 7.5
• Steering
• Steering Type: Re-Circulating Ball
• Turning Diameter - Wall to Wall (ft): 52.2
• Frame
• Sect Modulus Rails Only (in³): 15.14
• Frame RBM (N/A): 1,275,200
• Frame Strength (lbs): 80000
• Frame Thickness (in): 0
• Fuel Tank
• Fuel Tank Location: Left Front
• Aux Fuel Tank Location: Left Front
• Exterior Dimensions
• Wheelbase (in): 179
• Width, Max w/o mirrors (in): 96.7
• Height, Overall (in): 94.3
• Cab to Axle (in): 84
• Frame Width, Rear (in): 3.1
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.4
• Front Shoulder Room (in): 68
• Front Hip Room (in): 67.6
• Second Head Room (in): 38.1
• Second Leg Room (in): 31.6
• Second Shoulder Room (in): 68.1
• Second Hip Room (in): 67.3
• Summary
• Vehicle Name: Ford Super Duty F-750 Straight Frame
• Body Style: Extended Cab
